Enclosed Top Mount Custom Pumpers

CUSTOMIZED TO WORK AS HARD AS YOU DO.

Spartan Top Mount Pumpers are among the strongest in the industry and feature the industry’s #1 rated safety system.

Winter changes everything for emergency responders, which makes this enclosed top mount pumper a true game changer. Our enclosed top mount pumpers put the operator and the pump panel controls inside the custom cab with an unobstructed and clear view of the scene. The Spartan enclosed top mount is carefully engineered to keep your crew protected from the elements and allow you to own the scene.

Performance Stats

  • Also available on commercial chassis
  • Metro Star chassis 380-500 HP
  • Gladiator chassis 400-600 HP
  • Includes additional cab insulation and additional heaters
  • Electric or manual controls located inside enclosed cab area
  • Traditional or rescue-style pumper body options
  • 500 to 1500-gallon water tank available
  • Waterous, Darley or Hale pump up to 2250 GPM
  • Spartan’s 1-touch CAFS and other foam systems available
  • Strongest body in the industry with 20-year body warranty

Features And Benefits

Tor-Max and Tri-Max Body Construction

Delivers extra compartment space, reduces torsional resistance and improves structural stability.

Vibra Torq Body-Mount System

Reduces vibration and stress on the body for a smoother ride, requires less maintenance and leads to longer vehicle life.

Low Hose Bed

Improves access and increases safety through improved stability.

Custom Built-in Floor Dry

Keeps your interior compartments free from spilled material and torn bags; can be configured in a number of different areas.

Smart Storage

Optional storage around the wheel wells increases the amount of usable compartment space. Smart Storage compartments were designed to free up body compartment space and bring equipment to a more usable height.

Enclosed Pump Panel

Operates the pump in a controlled environment and places the pump controls where you need them to get the job done.

Spartan One-Touch CAFS

Allows for easy control and operation without manual processes or calculations. Once the pump is engaged and water is flowing, state-of-the-art electronics monitor components in a ready state. The system injects foam into the water and air into the appropriate discharge, sensing foam/water flow and eliminating slug flow.

SG-09 Auxiliary Power Unit, EMISSION-Reduction Technology

Our exclusive SG-09 Green Auxiliary Power Unit (APU) is designed to handle the rigors of the fire service and reduces the operation of the chassis engine while providing all electrical and HVAC capabilities.

Smart Step Compartment Access

Incorporates a slide-out step at the pump panel, rear or side of body to create a safer work environment.

Forward Cab Roof Design

All raised-roof applications include forward roof protection that extends over the driver and officer seating, offering more headroom and better line of site.

Independent Front Suspension

Spartan’s 20k and 24k independent front suspensions provide superior cramp angles with full air suspension, available with a range of tire sizes designed for easy service and maintenance.

Optimized Engine Tunnel

Increases the hip room for the driver and officer seating location as well as the rear crew floor space behind the engine tunnel, all without increasing the width of the cab. The rear of the tunnel is pushed forward to give an additional 2″ of leg room for the two center forward-facing crew, increasing leg room by +3.8%.

Most Spacious Cab

Spartan’s cabs offer the most room available with ergonomic designs, improved visibility, maximized storage, comfort and safety.

High Angle of Approach

This bumper gives you a high angle of approach for mobility options above and beyond the norm.

Enhanced Maneuverability

The tightest turn radius and the most maneuverable chassis on the market. The turning radius cramp angles range up to 53 degrees and offer up to a 19-degree approach angle, exceeding the NFPA 1901 standards.
