Rear Mount Custom Pumpers

CUSTOM-BUILT TO A HIGHER STANDARD.

Eliminate the large traditional pump house with Spartan’s Rear Mount Pumper and increase the maneuverability of your apparatus. Each Rear Mount Pumper is custom-built to the department’s needs and delivers maximized compartment space.

Each configuration features our exclusive body structure and mounting system, offering a durable framework that delivers more compartment space, a lower center of gravity, ergonomic controls and increased serviceability.

Performance Stats

  • Up to 2250 GPM
  • Also available on commercial chassis
  • Metro Star chassis 380-500 HP
  • Gladiator chassis 400-600 HP
  • Waterous, Darley, or Hale pump options
  • FoamPro, Waterous, Hale, CAFS foam systems
  • Stainless steel or aluminum body construction
  • 500 to 1500-gallon tank capacity as standard with larger options available
  • Vibra Torq body-mount system with 20-year body warranty
  • Compartment depths (12.5″ or 25.5″ upper/25.5″ lower)
  • Space-saving frame to provide greater storage capacity

Features And Benefits

Vibra Torq Body-Mount System

Reduces vibration and stress on the body for a smoother ride, requires less maintenance and leads to longer vehicle life.

Tor-Max and Tri-Max Body Construction

Delivers extra compartment space, reduces torsional resistance and improves structural stability.

Rear Mount Pump

Rear mount pumpers provide an added level of flexibility with versatile pump control and discharge locations that provide a safe work environment with high visibility of the scene.

SG-09 Auxiliary Power Unit, EMISSION-Reduction Technology

Our exclusive SG-09 Green Auxiliary Power Unit (APU) is designed to handle the rigors of the fire service and reduces the operation of the chassis engine while providing all electrical and HVAC capabilities.

Smart Storage

Optional storage around the wheel wells increases the amount of usable compartment space. Smart Storage compartments were designed to free up body compartment space and bring equipment to a more usable height.

Spartan One-Touch CAFS

Allows for easy control and operation without manual processes or calculations. Once the pump is engaged and water is flowing, state-of-the-art electronics monitor components in a ready state. The system injects foam into the water and air into the appropriate discharge, sensing foam/water flow and eliminating slug flow.

Independent Front Suspension

Spartan’s 20k and 24k independent front suspensions provide superior cramp angles with full air suspension, available with a range of tire sizes designed for easy service and maintenance.

Forward Cab Roof Design

All raised-roof applications include forward roof protection that extends over the driver and officer seating, offering more headroom and better line of site.

Safe and Easy Access

Wide egress steps and walkways provide easy access to and from the ladder.

Optimized Engine Tunnel

Increases the hip room for the driver and officer seating location as well as the rear crew floor space behind the engine tunnel, all without increasing the width of the cab. The rear of the tunnel is pushed forward to give an additional 2″ of leg room for the two center forward-facing crew, increasing leg room by +3.8%.

Most Spacious Cab

Spartan’s cabs offer the most room available with ergonomic designs, improved visibility, maximized storage, comfort and safety.

High Angle of Approach

This bumper gives you a high angle of approach for mobility options above and beyond the norm.

Enhanced Maneuverability

The tightest turn radius and the most maneuverable chassis on the market. The turning radius cramp angles range up to 53 degrees and offer up to a 19-degree approach angle, exceeding the NFPA 1901 standards.
